Wireless Network Projection
94
a
If you need to assign the SSID manually, select SSID to enter the
SSID.
i
For the Advanced connection mode, assign the IP settings for your
network as necessary.
If your network assigns addresses automatically, select IP Settings to
set the DHCP setting to On.
If you must set addresses manually, select IP Settings to set the
DHCP setting to Off, and then enter the projector's IP Address,
Subnet Mask, and Gateway Address as necessary.
If you want to connect the projector to the network using IPv6, select
IPv6 Settings to set the IPv6 setting to On, and then set the Auto
Configuration and Use Temporary Address settings as necessary.
j
To prevent the SSID or IP address from being displayed on the LAN
standby screen and Home screen, set the SSID Display setting or the IP
Address Display setting to Off.
k
When you finish selecting settings, select Complete and follow the on-
screen instructions to save your settings and exit the menus.
l
Press the [LAN] button on the remote control.
The wireless network settings are complete when you see the correct IP
address on the LAN standby screen.
When you have finished making wireless settings for your projector, you need
to select the wireless network on your computer. Then start the network
software to send images to your projector through a wireless network.
Selecting Wireless Network Settings in Windows
Before connecting to the projector, select the correct wireless network on your
computer.
a
To access your wireless utility software, click the network icon on the
Windows taskbar.
b
When connecting in Advanced connection mode, select the network
name (SSID) of the network the projector is connecting to.
c
Click Connect.

Table of Contents

Other manuals for Epson EB-W06

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-W06 and is the answer not in the manual?

Epson EB-W06 Specifications

General IconGeneral
Contrast Ratio16, 000:1
Weight2.5 kg
Projection System3LCD
Aspect Ratio16:10
Projection Ratio1.30 - 1.56:1
Screen Size33 inches - 320 inches
Projection Lens F Number1.49 - 1.72
Projection Lens Focal Length16.9 - 20.28 mm
Projection Lens FocusManual
SecurityKensington lock, Password protection
3DNo
ResolutionWXGA (1280 x 800)
Brightness3700 lumens
Lamp Life12000 hours (Eco)
Keystone CorrectionVertical: ±30 degrees, Horizontal: ±30 degrees
ConnectivityHDMI, VGA, USB
LCD Panel0.59-inch with MLA (D10)
LampUHE, 210 W
ZoomFactor: 1.2
Noise Level37 dB (Normal)
Dimensions302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption0.3 W (Standby)
