Projector Connections
29
a
If the projector does not project any images, do one of the following:
Windows: Click All Programs > EPSON Projector > Epson USB
Display > Epson USB Display Ver.x.xx.
Mac: Double-click the USB Display icon in the Application folder.
When you finish projection, do one of the following:
Windows: Disconnect the USB cable. You do not need to operate
Safely Remove Hardware.
Mac: Select Disconnect from the USB Display icon menu on the
menu bar or Dock, and then disconnect the USB cable.
gg Related Links
"USB Display System Requirements" p.203
"List of Functions" p.10
Connecting to a Computer for HDMI Video and Audio
If your computer has an HDMI port, you can connect it to the projector using
an HDMI cable and send the computer's audio with the projected image.
a
To connect a Mac that does not have an HDMI port, you need an
adapter that allows you to connect to the projector's HDMI port.
Contact Apple for compatible adapter options. Older Mac computers
(2009 and earlier) may not support audio through the HDMI port.
a
Connect the HDMI cable to your computer's HDMI output port.
b
Connect the other end to the projector's HDMI port.
a
If you have problems hearing audio through the HDMI connection,
connect one end of a commercially available 3.5 mm stereo mini-jack
audio cable to the projector's Audio port and the other end to your
computer's audio out port. Select the audio input port you connected
to in the projector's Extended menu.
s Extended > A/V Settings > Audio Settings > HDMI Audio
Output
s Extended > A/V Settings > Audio Settings > HDMI1 Audio
Output
s Extended > A/V Settings > Audio Settings > HDMI2 Audio
Output
gg Related Links
"Projector Setup Settings - Extended Menu" p.134
"List of Functions" p.10
Connecting to Video Sources
Follow the instructions in these sections to connect video devices to the
projector.

Table of Contents

Other manuals for Epson EB-W06

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-W06 and is the answer not in the manual?

Epson EB-W06 Specifications

General IconGeneral
Contrast Ratio16, 000:1
Weight2.5 kg
Projection System3LCD
Aspect Ratio16:10
Projection Ratio1.30 - 1.56:1
Screen Size33 inches - 320 inches
Projection Lens F Number1.49 - 1.72
Projection Lens Focal Length16.9 - 20.28 mm
Projection Lens FocusManual
SecurityKensington lock, Password protection
3DNo
ResolutionWXGA (1280 x 800)
Brightness3700 lumens
Lamp Life12000 hours (Eco)
Keystone CorrectionVertical: ±30 degrees, Horizontal: ±30 degrees
ConnectivityHDMI, VGA, USB
LCD Panel0.59-inch with MLA (D10)
LampUHE, 210 W
ZoomFactor: 1.2
Noise Level37 dB (Normal)
Dimensions302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption0.3 W (Standby)
