Saving a User Pattern
78
There are four types of patterns pre-registered in the projector, such as ruled
lines and grid patterns. You can project these patterns to aid in presentations
using the Pattern Display settings.
You can also save the image that is currently being projected as a User
Pattern.
a
Once you save a User Pattern, the pattern cannot be returned to the
factory default.
a
Project the image you want to save as the User Pattern, and then press
the [Menu] button on the control panel or remote control.
b
Select the Settings menu and press [Enter].
c
Select Pattern > User Pattern and press [Enter].
You see a prompt asking if you want to use the displayed image as a
User Pattern.
a
• Adjustments such as Keystone, E-Zoom, or Aspect are
temporarily cancelled when you select User Pattern.
• You cannot save digital images protected by HDCP technology
as a User Pattern.
d
Select Yes and press [Enter].
You see a prompt asking if you want to save the image as the User
Pattern.
e
Select Yes and press [Enter].
You see a completion message.

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
