Projector Connections
34
Connecting a Microphone
You can connect a microphone to the projector's Mic port to provide audio
support during presentations.
a
Plug-in-power is not supported.
If you want to output audio from a microphone when the projector
is turned off, select Always On as the A/V Output setting in the
projector's Extended menu.
s Extended > A/V Settings > A/V Output
Adjust Mic Input Level if the microphone audio is difficult to hear,
or if it is too loud resulting in a crackling sound.
s Settings > Mic Input Level
a
Connect the microphone cable to the projector's Mic port.
b
Turn on the microphone, if necessary.
gg Related Links
"Projector Setup Settings - Extended Menu" p.134
"Projector Feature Settings - Settings Menu" p.132
"List of Functions" p.10

Table of Contents

Other manuals for Epson EB-W06

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-W06 and is the answer not in the manual?

Epson EB-W06 Specifications

General IconGeneral
Contrast Ratio16, 000:1
Weight2.5 kg
Projection System3LCD
Aspect Ratio16:10
Projection Ratio1.30 - 1.56:1
Screen Size33 inches - 320 inches
Projection Lens F Number1.49 - 1.72
Projection Lens Focal Length16.9 - 20.28 mm
Projection Lens FocusManual
SecurityKensington lock, Password protection
3DNo
ResolutionWXGA (1280 x 800)
Brightness3700 lumens
Lamp Life12000 hours (Eco)
Keystone CorrectionVertical: ±30 degrees, Horizontal: ±30 degrees
ConnectivityHDMI, VGA, USB
LCD Panel0.59-inch with MLA (D10)
LampUHE, 210 W
ZoomFactor: 1.2
Noise Level37 dB (Normal)
Dimensions302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption0.3 W (Standby)
