Wireless Network Projection from a Mobile Device (Screen Mirroring)
103
d
Select Add a wireless display.
You see a list of available devices.
e
Select the projector's Display Name from the list.
f
If you see the PIN entry screen on your computer, enter the PIN code
displayed on the Screen Mirroring standby screen or at the bottom
right of the projected image.
The projector displays the image from your computer.
a
It may take some time until the connection is established. While
connecting, do not disconnect the projector's power cord. Doing
so may cause your device to freeze or malfunction.

Table of Contents

Other manuals for Epson EB-W06

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-W06 and is the answer not in the manual?

Epson EB-W06 Specifications

General IconGeneral
Contrast Ratio16, 000:1
Weight2.5 kg
Projection System3LCD
Aspect Ratio16:10
Projection Ratio1.30 - 1.56:1
Screen Size33 inches - 320 inches
Projection Lens F Number1.49 - 1.72
Projection Lens Focal Length16.9 - 20.28 mm
Projection Lens FocusManual
SecurityKensington lock, Password protection
3DNo
ResolutionWXGA (1280 x 800)
Brightness3700 lumens
Lamp Life12000 hours (Eco)
Keystone CorrectionVertical: ±30 degrees, Horizontal: ±30 degrees
ConnectivityHDMI, VGA, USB
LCD Panel0.59-inch with MLA (D10)
LampUHE, 210 W
ZoomFactor: 1.2
Noise Level37 dB (Normal)
Dimensions302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption0.3 W (Standby)
