Installing the Quick Wireless Connection USB Key
When installing the optional Quick Wireless Connection USB Key, you
need to remove the Wireless LAN unit first, and then connect the Quick
Wireless Connection USB Key to the USB-A port.
a
Turn on the projector, and then press the [LAN] button on the
remote control.
The LAN standby screen is displayed.
b
Check that the SSID and IP address information are displayed on
the LAN standby screen, and then remove the Wireless LAN
unit.
c
Connect the Quick Wireless Connection USB Key to the USB-A
port.
d
When the message "Network information update complete.
Remove the Quick Wireless Connection USB Key Adapter." is
displayed, remove the Quick Wireless Connection USB Key.
e
Reinstall the Wireless LAN unit on the projector.
f
Connect the Quick Wireless Connection USB Key to the computer
you are using.
For the steps from here on, see the User's Guide supplied with the
Quick Wireless Connection USB Key.
Connecting Equipment
32

Epson EB-W22 Specifications


color light output	3, 000 lumen - 2, 100 lumen (economy)
white light output	3, 000 lumen - 2, 100 lumen (economy)
resolution	WXGA, 1280 x 800, 16:10
contrast ratio	10, 000:1
lamp power	200 W

Optical

projection ratio	1.30 - 1.56:1
zoom factor	1.2
projection size	33 inches - 318 inches
projection distance wide/tele	1.68 m - 2.02 m (60 inch screen)
focal distance	16.9 mm - 20.28 mm

Connectivity

usb display function	3 in 1: Image / Mouse / Sound
interfaces	USB 2.0 Type B, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), VGA in (2x), VGA out, HDMI in, Composite in, Component in (2x), S-Video in, RGB in (2x), Stereo mini jack audio out, Stereo mini jack audio in (2x), Cinch audio in
epson iprojection app	Ad-Hoc / Infrastructure

General

energy use	270 W, 223 W (economy), 0.47 W (standby)
dimensions single carton	363 x 397 x 160 mm
carton weight	4.11 Kg
