Configuration Menu Table
Settable items vary depending on the model being used and the image
signal and source being projected.
Top Menu Name Submenu Name Items or Setting Values
Image menu
s p.85
Color Mode Dynamic, Presentation, Theatre,
Photo, Sports, sRGB, Blackboard,
and Whiteboard
Brightness -24 - 24
Contrast -24 - 24
Color Saturation -32 - 32
Tint -32 - 32
Sharpness -5 - 5
Abs. Color Temp. 5000K to 10000K
Color Adjustment Red: -16 to 16
Green: -16 to 16
Blue: -16 to 16
Auto Iris Off, Normal, High Speed
Signal menu
s p.86
Auto Setup On and Off
Resolution Auto, Wide, and Normal
Tracking -
Sync. 0 - 31
Position Up, Down, Left, and Right
Progressive Off, Video, and Film/Auto
Noise Reduction Off, NR1, and NR2
HDMI Video Range Auto, Normal, and Expanded
Input Signal Auto, RGB, and Component
Top Menu Name Submenu Name Items or Setting Values
Video Signal Auto, NTSC, NTSC4.43, PAL,
M-PAL, N-PAL, PAL60, and
SECAM
Aspect Normal, Auto, 4:3, 16:9, Full,
Zoom, and Native
Overscan Auto, Off, 4%, and 8%
Image Processing Fine, Fast
Settings menu
s p.88
Keystone H/V-Keystone and Quick Corner
Zoom
(EB-S21/EB-S17 only)
-
Control Panel Lock Full Lock, Partial Lock, and Off
Pointer Shape Pointer 1, 2, and 3
Volume 0 - 10
Remote Receiver Front/Rear, Front, Rear, and Off
User Button Power Consumption, Info,
Progressive, Resolution, and
Pattern Display
Pattern Pattern Display, Pattern Type,
User Pattern, and Test Pattern
Extended menu
s p.89
Display Messages, Display Background,
Startup Screen, and A/V Mute
User's Logo -
Projection Front, Front/Ceiling, Rear, and
Rear/Ceiling
Operation Direct Power On, High Altitude
Mode, Startup Source Search
A/V Settings A/V Output, Audio Output,
HDMI Audio Output
Language 15 or 36 languages
*1
ECO menu Power Consumption Normal and ECO
List of Functions
