Epson EB-W22 User Manual

Selecting the Projection Quality (Selecting Color Mode)...................46
Setting Auto Iris ..............................................47
Changing the Aspect Ratio of the Projected Image.......................47
Changing methods..........................................48
Changing the aspect mode.....................................48
Useful Functions
Projection Functions ....................................... 52
Projecting Without a Computer (PC Free).............................52
Specifications for files that can be projected using PC Free...............52
PC Free examples...........................................52
PC Free operating methods.....................................53
Projecting the selected image...................................55
Projecting image files in a folder in sequence (Slideshow)................56
Image file display settings and Slideshow operation settings..............57
Hiding the Image and Sound Temporarily (A/V Mute).....................57
Freezing the Image (Freeze)......................................58
Pointer Function (Pointer)........................................58
Enlarging Part of the Image (E-Zoom)................................ 59
Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse) . . . . . . 60
Saving a User's Logo........................................... 61
Saving User Pattern ............................................63
Security Functions ......................................... 65
Managing Users (Password Protect) .................................65
Kinds of Password Protect......................................65
Setting Password Protect ......................................65
Entering the Password........................................66
Restricting Operation (Control Panel Lock)............................67
Anti-Theft Lock............................................... 69
Installing the wire lock........................................69
Monitoring and Controlling ................................ 70
EasyMP Monitor..............................................70
Changing Settings Using a Web Browser (Web Control)....................70
Projector setup............................................. 70
Displaying the Web Control screen...............................70
Displaying the Web Remote screen...............................71
Using the Mail Notification Function to Report Problems...................72
Reading Error Notification Mail..................................72
Management Using SNMP.......................................73
ESC/VP21 Commands........................................... 73
Command list.............................................. 73
Cable layouts.............................................. 74
About PJLink (EB-X25/EB-W22/EB-X22/EB-X20 Only)...................... 75
About Crestron RoomView
®
(EB-X25/EB-W22/EB-X22/EB-X20 only)...........75
Operating a projector from your computer..........................76
About Event ID ............................................ 80
Configuration Menu
Using the Configuration Menu .............................. 82
List of Functions ........................................... 83
Configuration Menu Table.......................................83
Network menu ............................................. 84
Image Menu .................................................85
Signal Menu................................................. 86
Settings Menu................................................88
Extended Menu ...............................................89
Network Menu ...............................................91
Notes on operating the Network menu .............................91
Soft keyboard operations......................................92
Basic menu ................................................93
Wireless LAN menu (EB-X21/EB-S21/EB-X17/EB-S17 only) . . . . . . . . . . . . . . . . 93
Security menu (EB-X21/EB-S21/EB-X17/EB-S17 only)....................95
Wired LAN menu (EB-X25/EB-W22/EB-X22/EB-X20 only).................96
Mail menu................................................97
Others menu..............................................98
Reset menu............................................... 99
ECO Menu..................................................99
Info Menu (Display Only)........................................100
Contents
4

Epson EB-W22 Specifications


color light output	3, 000 lumen - 2, 100 lumen (economy)
white light output	3, 000 lumen - 2, 100 lumen (economy)
resolution	WXGA, 1280 x 800, 16:10
contrast ratio	10, 000:1
lamp power	200 W

Optical

projection ratio	1.30 - 1.56:1
zoom factor	1.2
projection size	33 inches - 318 inches
projection distance wide/tele	1.68 m - 2.02 m (60 inch screen)
focal distance	16.9 mm - 20.28 mm

Connectivity

usb display function	3 in 1: Image / Mouse / Sound
interfaces	USB 2.0 Type B, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), VGA in (2x), VGA out, HDMI in, Composite in, Component in (2x), S-Video in, RGB in (2x), Stereo mini jack audio out, Stereo mini jack audio in (2x), Cinch audio in
epson iprojection app	Ad-Hoc / Infrastructure

General

energy use	270 W, 223 W (economy), 0.47 W (standby)
dimensions single carton	363 x 397 x 160 mm
carton weight	4.11 Kg
