Button Function
A/V Mute Turns the video and audio on or off.
s "Hiding the Image and Sound Temporarily (A/V
Mute)" p.57
B
Switch to the image from the selected input source. To display input sources that
are not shown in Source List, click (a) or (b) to scroll up or down.
You can change the source name if necessary.
C
You can perform the following operations when you click the buttons. To display
buttons that are not shown in Source List, click (c) or (d) to scroll left or right.
Button Function
Freeze Images are paused or unpaused.
s "Freezing the Image (Freeze)" p.58
Contrast You can adjust the difference between light and dark in
the images.
Brightness You can adjust the image brightness.
Color You can adjust the color saturation for the images.
Sharpness You can adjust the image sharpness.
Zoom
Click the [z] button to enlarge the image without
changing the projection size. Click the [x] button to
reduce an image that was enlarged with the [
z
] button.
Click the [
], [ ], [ ], or [ ] buttons to change the
position of an enlarged image.
s
"Enlarging Part of the Image (E-Zoom)" p.59
D
The [ ], [ ], [ ], and [ ] buttons perform the same operations as the [ ],
[
], [ ], and [ ] buttons on the remote control. You can perform the
following operations when you click the other buttons.
Button Function
OK
Performs the same operation as the [
] button on the
remote control.
s "Remote Control" p.16
Menu Displays and closes the Configuration menu.
Auto If clicked while projecting analog RGB signals from
Computer1 port or Computer2 port, automatically
optimizes the image by adjusting the Tracking, Sync.,
and Position.
Search Changes to the next input source that is sending an
image.
s "Automatically Detect Input Signals and Change the
Projected Image (Source Search)" p.35
Esc Performs the same operation as the [Esc] button on the
remote control.
s "Remote Control" p.16
E
You can perform the following operations when you click the tabs.
Tab Function
Contact IT Help Displays the Help Desk window. Used to send messages
to, and receive messages from, the administrator using
Crestron RoomView
®
Express.
Info Displays information on the projector that is currently
connected.
Tools Changes settings in the projector that is currently
connected. See the next section.
Using the tools window
The following window is displayed when you click the Tools tab on the
operation window. You can use this window to change settings in the
projector that is currently connected.
Monitoring and Controlling
77
To Next Page
