• The last 5 error logs are displayed (the latest on top). None is displayed if there’s no
error.
• In the case of the display in the previous page, the latest error is “Internal Overheat”.
When error occurred, Total Operation Time was 9 hours 46 minutes 57 seconds, Lamp
Operation Time was 5 hours 36 minutes 27 seconds, the time after the lamp turned ON
was 0 hours 2 minutes 23 seconds, the projector’s status was “Lamp ON”.
• The 2nd latest error is “Fan Error”. When error occurred, Total Operation Time was 8
hours 35 minutes 34 seconds, Lamp Operation Time was 5 hours 34 minutes 4 seconds,
the time after the lamp turned ON was 0 hours 0 minutes 1 second, the projector’s status
was “Warming up”.
Table 5-1. Error log items
Item Contents Representation
Error Log
CD Error Code Two alphabets
TOT Total Operation Time
h: 5-digit number (00000-
65535)
Over 65535: “65535” (Not
cleared to “0.”)
m: 2-digit number (00-59)
s: 2-digit number (00-59)
LOT Lamp Operation Time
POT Time after Lamp is ON
ST PJ (Projector)’s status
Acquired data of PWR? of the
ESC/VP21 command
Item Contents
Representation
Error Count
TH Internal overheat
2-digit number (00-99)
Over 99: “99”
(Not cleared to “0.”)
FN Fan error
SE Thermistor error
LE Lamp burnt out
LF Lighting failure
RA Internal error (RAM)
RO Internal error (ROM)
II Internal error (I2C)
ID Internal error (DR)
LC Lamp cover open
EC Electric capacitor error
CF Cinema filter error
AI Auto Iris error
RS Sub system ROM error
RP Sub system PW error
DU DVD unit error
WL Air filter wind lowered
WS Wind sensor error
PB Power error (Ballast)
IV Internal error (SO)
SH Shutter error
FE
Cooling system error
(peltier device)
FP
Cooling system error
(pump)
VE Exhaust shutter error
Control
Control data 1
Thermal data of each
thermistor
Acquired data of TEMP?
of the ESC/VP21 command
Control data 2 Voltage of each fan

Epson EB-X12 Specifications

General

Matrix size	0.55 \
Projection distance	- m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Aspect ratio	4:3
RS-232 ports	0
Dimensions (WxDxH)	295 x 228 x 77 mm
Connectivity technology	Wired
Maximum operating altitude	2286 m
Offset	8:1 %
Zoom capability	Yes
Focal length range	1.58 - 20.28 mm
Lamp type	UHE
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
S-Video inputs quantity	1
Analog signal format system	-
RMS rated power	2 W
Product type	Standard throw projector
Product color	Black, White
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.47 W
Power consumption (typical)	283 W
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	29 dB
Operating temperature (T-T)	5 - 35 °C
Pallet width	800 mm
Pallet height	2204 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Weight	2300 g
Package depth	360 mm
Package width	335 mm
Package height	158 mm
Package weight	3847 g
