EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480

Troubleshooting CONFIDENTIAL

SEIKO EPSON 23 Revision C

2.3 Exterior Check

When repairing this product, carry out exterior check of the target parts/units as

necessary.

 Check Items

2.3.1 Parts Layout Diagrams

The following are the diagrams to confirm and locate the parts and/or components to be

repaired. The parts names used here indicate the references linked to the page titles for

their disassembling procedures.

Target part Check item

Upper Case

Any damage/deformation/cracking due to external

forces?

Is it fixed to the Lower Case correctly?

Any foreign object/dirt on the IR receivers (Front

and Rear)?

IF Case

Any damage/deformation/cracking due to external

forces?

Is it fixed with screws correctly?

Is it fixed to the Lower Case and Upper Case

correctly?

SW Board

Is it fixed to Upper Case correctly?

Any stuck buttons?

Does Buttons work smoothly?

Lamp Cover

Is it fixed to Upper Case correctly?

Any damage on the latch to operate the Interlock

Switch? (Check for it with the cover removed.)

Air Filter Cover

Any damage/deformation/cracking due to external

forces?

Is it fixed to the Upper Case correctly?

Projection Lens

Does Focus Ring work smoothly?

Does Zoom Ring work smoothly?

Any dirt/scratches on the projection lens?

Lower Case

Any damage/deformation/cracking due to external

forces?

Any foreign object/dirt on the filter cover or the

vents?

Foot

Does Front Foot work smoothly to adjust height?

Any Foot Rubber detached?

AC Inlet

Any deformation/discoloration on the connector/

terminals?

Any damage on the socket?

Interfaces

Any deformation/discoloration on the connector/

terminals?

Any foreign objects on the connectors/terminals?

Air Filter

Is it fixed correctly?

Any dirt on the filter? (check for it with the filter

removed.)

Any dirt/foreign materials on the fan inside the

filter?

HK Assy

Any damage/deformation/cracking due to external

forces?

Is it fixed to Upper Case correctly?

Does it work smoothly?

Lens Shutter

Any deformation/discoloration on it?

Is it fixed to Upper Case correctly?

Does it work smoothly?

Lamp

Any deformation/discoloration on the frame?

Any deformation/discoloration on the connector?

Are the screws that secure the Lamp tightened

securely?

Any dirt on the glass surface?
