a
If not all of the files and folders are displayed on the current
screen, press the [
]
] button on the remote control, or position
the cursor on Next Page at the bottom of the screen and press
the [
] button.
To return to the previous screen, press the [[] button on the
remote control, or position the cursor on Previous Page at the
top of the screen and press the [
] button.
b
Press the [ ] button.
The selected image is displayed.
When a folder is selected, the files in the selected folder are
displayed. To return to the previous screen, position the cursor on
Back to Top and press the [
] button.
Rotating images
You can rotate the played images in 90˚ increments. The rotating function
is also available during Slideshow.
a
Play images, or run Slideshow.
b
While projecting, press the [ ] or [ ] button.
Stopping Slideshow
To close Slideshow, disconnect the USB device from the USB port on the
projector. For digital cameras, hard disks, and so on, turn off the power to
the device and then remove.
Projecting the selected image
Attention
Do not disconnect the USB storage device while it is being accessed.
Slideshow may not operate correctly.
a
Start Slideshow.
The file list screen is displayed.
s "Starting Slideshow" p.39
Projection Functions
41

Table of Contents

Other manuals for Epson EH-TW480

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EH-TW480 and is the answer not in the manual?

Epson EH-TW480 Specifications

General IconGeneral
Matrix size0.59 \
Number of colors16.78 million colors
Projection distance1.68 - 2.02 m
Projection technologyLCD
Contrast ratio (typical)3000:1
Screen size compatibility33 - 318 \
Projector native resolutionWXGA (1366x768)
Keystone correction, horizontal30 °
Aspect ratio16:10
RS-232 ports-
Dimensions (WxDxH)295 x 79 x 228 mm
Connectivity technologyWired
F-number (relative aperture)1.58
FocusAuto
Offset100 %
Throw ratio1.3 - 1.56:1
Optical zoom1.2 x
Focal length range16.9 - 20.28 mm
Lamp typeUHE
Lamp power200 W
Light source typeLamp
Service life of light source750 h
Service life of light source (economic mode)5000 h
DVI portNo
Composite video in0
USB connector typeUSB Type-A, USB Type-B
USB 2.0 ports quantity2
S-Video inputs quantity1
HD-ReadyYes
Supported video modes720p
RMS rated power2 W
Product colorBlack
LED indicatorsPower, Y
Market positioningHome cinema
Cable lock slot typeKensington
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)3.3 W
Power consumption (typical)270 W
Noise level29 dB
Country of originChina
Operating altitude0 - 2286 m
Operating temperature (T-T)5 - 35 °C
Pallet width800 mm
Pallet height3834 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet72 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Weight2300 g
Package depth361 mm
Package width336 mm
Package height165 mm
Package weight3750 g
