Configuration Menu Table
Settable items vary depending on the model being used and the image
signal and source being projected.
Top Menu Name Submenu Name Items or Setting Values
Image menu
s p.58
Color Mode Dynamic, Living Room, Theatre,
Game
Brightness -24 to 24
Contrast -24 to 24
Color Saturation -32 to 32
Tint -32 to 32
Sharpness -5 to 5
Color Temp. High, Medium, and Low
Color Adjustment Red: -16 to 16
Green: -16 to 16
Blue: -16 to 16
Auto Iris On and Off
Signal menu
s p.59
Auto Setup On and Off
Resolution Auto, Wide, and Normal
Tracking -
Sync. 0 to 31
Position Up, Down, Left, and Right
Progressive On, Off, Video, and Film/Auto
Noise Reduction Off, NR1, and NR2
HDMI Video Range Auto, Normal, and Expanded
Input Signal Auto, RGB, and Component
Video Signal Auto, NTSC, NTSC4.43, PAL,
M-PAL, N-PAL, PAL60, and
SECAM
Top Menu Name Submenu Name Items or Setting Values
Aspect Normal, Auto, 4:3, 16:9, Full,
Zoom, and Native
Overscan Auto, Off, 4%, and 8%
Settings menu
s p.61
Keystone H/V-Keystone and Quick Corner
Zoom -
Control Panel Lock Full Lock, Partial Lock, and Off
Pointer Shape Pointer 1, 2, and 3
Power Consumption Normal and ECO
Volume 0 to 10
Remote Receiver Front/Rear, Front, Rear and Off
User Button Brightness Control, Info,
Progressive, Test Pattern,
Resolution
Test Pattern -
Extended menu
s p.62
Display Messages, Display Background,
Startup Screen, and A/V Mute
User's Logo -
Projection Front, Front/Ceiling, Rear, and
Rear/Ceiling
Operation Direct Power On, Sleep Mode,
Sleep Mode Timer, Lens Cover
Timer, and High Altitude Mode
Standby Mode Communication On and
Communication Off
USB Type B USB Display and Link 21L
Language 15 or 35 languages
*1
Info menu
s p.63
Lamp Hours -
Source -
Input Signal -
