Interference or distortion appear in images
Check Remedy
Is the image signal format setting correct?
(Only when projecting images from a video source)
Change the setting according to the signal for the connected equipment.
s Signal - Video Signal p.59
Are the cables connected correctly? Check that all the cables required for projection are securely connected.
s "Connecting Equipment" p.17
Is an extension cable being used? If an extension cable is used, electrical interference may affect the signals. Use the cables supplied with the projector to
check if the cables you are using may be causing the problem.
Is the correct resolution selected?
(Only when projecting computer images)
Set the computer so that the signals being output are compatible with the projector.
s "Supported Monitor Displays" p.91
s Computer's documentation
Are the
Sync. g and Tracking g settings adjusted correctly?
(Only when projecting computer images)
Press the [Auto] button on the remote control or the [
] button on the control panel to perform automatic adjustment.
If the images are not adjusted correctly even after performing automatic adjustment, you can also make adjustments
from the Configuration menu.
s Signal - Tracking, Sync. p.59
Is Transfer layered window selected?
(Only when projecting USB Display)
Click All Programs - EPSON Projector - Epson USB Display - Epson USB Display Vx.xx Settings, and then clear the
Transfer layered window checkbox.
The image is truncated (large) or small, or the aspect is not suitable
Check Remedy
Is a wide panel computer image being projected?
(Only when projecting computer images)
Change the setting according to the signal for the connected equipment.
s Signal - Resolution p.59
Is the image still being enlarged by E-Zoom? Press the [Esc] button on the remote control to cancel E-Zoom.
s "Enlarging Part of the Image (E-Zoom)" p.46
Is the image position adjusted correctly? (Only when projecting analog RGB signals input from the Computer port)
Press the [Auto] button on the remote control or the [
] button on the control panel to adjust the position.
You can also adjust the position from the Configuration menu.
s Signal - Position p.59
Problem Solving
74

Epson EH-TW480 Specifications

General

Matrix size	0.59 \
Number of colors	16.78 million colors
Projection distance	1.68 - 2.02 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	33 - 318 \
Projector native resolution	WXGA (1366x768)
Keystone correction, horizontal	30 °
Aspect ratio	16:10
RS-232 ports	-
Dimensions (WxDxH)	295 x 79 x 228 mm
Connectivity technology	Wired
F-number (relative aperture)	1.58
Focus	Auto
Offset	100 %
Throw ratio	1.3 - 1.56:1
Optical zoom	1.2 x
Focal length range	16.9 - 20.28 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	750 h
Service life of light source (economic mode)	5000 h
DVI port	No
Composite video in	0
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
S-Video inputs quantity	1
HD-Ready	Yes
Supported video modes	720p
RMS rated power	2 W
Product color	Black
LED indicators	Power, Y
Market positioning	Home cinema
Cable lock slot type	Kensington
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	3.3 W
Power consumption (typical)	270 W
Noise level	29 dB
Country of origin	China
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C
Pallet width	800 mm
Pallet height	3834 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	72 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Weight	2300 g
Package depth	361 mm
Package width	336 mm
Package height	165 mm
Package weight	3750 g
