Epson EH-TW6250 User Manual

Projector Parts and Functions
11
Name Function
F
Power inlet Connects the power cord to the projector.
gg Related Links
• "Projector Connections" p.20
Projector Parts - Base
Name Function
A
Ceiling mount fixing
points (three points)
Attach the optional ceiling mount here when
suspending the projector from a ceiling.
B
Air exhaust vent Exhaust vent for air used to cool the projector
internally.
C
Rear feet When the projector is set up on a surface such as a
desk, turn to extend and retract the feet to adjust the
horizontal tilt.
D
Security cable
attachment point
Pass a commercially available wire lock through here
and lock it in place.
You can also attach the optional safety wire here to
prevent the projector from falling from the ceiling or
wall.
E
Air intake vent Takes in air to cool the projector internally.
F
Front adjustable foot When the projector is set up on a surface such as a
desk, extend the foot to adjust the position of the
image.
gg Related Links
• "Adjusting the Image Height" p.35
• "Installing a Security Cable" p.63
Projector Parts - Projector Remote Control
You can operate your projector and Epson streaming media player
(ELPAP12) using this remote control.

Epson EH-TW6250 Specifications

General

Heat dissipation	1.023 BTU/h
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	35000:1
Screen size compatibility	40 - 500 \
Projection distance (wide)	2.34 - 3.81 m
Projector native resolution	4K+ (5120x3200)
Keystone correction, horizontal	±30 °
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4500 h
Service life of light source (economic mode)	7500 h
Focus	Manual
Throw ratio	1.32 - 2.15:1
Focal length range	18.2 - 29.2 mm
Vertical lens shift range	60 - 60 %
Smart TV	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
HDMI version	2.3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	36 dB
Noise level (economic mode)	28 dB
Placement	Ceiling, Desktop
Product type	Short throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Video color modes	Cinema, Dynamic, Natural, Vivid
Quantity per pack	1 pc(s)
Cables included	Power
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	301 W
Power consumption (economy mode)	231 W

Weight and Dimensions

Depth	275 mm
Width	333 mm
Height	131 mm
Weight	4100 g
