Epson EH-TW9300W - Specifications

To Next Page

To Previous Page

Appendix

120

Signal Refresh Rate (Hz) Resolution (dots)

4K x 2K 24/25/30 3840 x 2160

4K x 2K (SMPTE) 24 4096 x 2160

HDMI4 port only

When projecting in WirelessHD, the following signals are not supported.

4K x 2K(SMPTE): 24 Hz
