Epson EMP-S3 User Manual

59
Maintenance
PROCEDURE
A
After you turn off the projector’s power, and the
confirmation buzzer beeps twice, disconnect the
power cable.
B
Wait until the lamp has cooled down, then remove the
lamp cover from the base of the projector.
Loosen the lamp cover fixing screw with the screwdriver that is
supplied with the spare lamp (or your own cross head
screwdriver).
Then slide the lamp cover straight forward and lift it to remove.
C
Loosen the two lamp fixing screws.
Loosen the two lamp fixing screws with the screwdriver that is
supplied with the spare lamp (or your own cross head
screwdriver).
D
Take out the lamp.
Hold the lamp as shown in the illustration below and lift it up
and out of the projector.
If the lamp is broken replace it with a new lamp, or contact your
local dealer for further advice. If replacing the lamp yourself,
be careful to avoid pieces of broken glass.

Epson EMP-S3 Specifications

General

Brightness	1600 ANSI lumens
Resolution	800 x 600 (SVGA)
Contrast Ratio	400:1
Display Technology	3LCD
Screen Size	30 - 300 inches
Lamp Type	170W UHE
Lamp Life	3000 hours (standard), 4000 hours (eco mode)
Projection Lens	Manual focus
Input Ports	VGA, Composite, S-Video
Output Ports	VGA
Operating Temperature	5°C to 35°C
