EPSON EPL-6200/EPL-6200L Revision A
Product Description External Appearance and Parts Name 33
1.3 External Appearance and Parts Name
1.3.1 Overall Dimensions of EPL-6200
Figure 1-6 (p.33) to Figure 1-9 (p.33) show the overall dimensions of EPL-6200.
Figure 1-6. Front View of EPL-6200
Figure 1-7. Right Side View with Output Tray in Use
Figure 1-8. Right Side View with Lower Cassette installed
Figure 1-9. Right Side View with Lower Cassette
and Duplex Unit installed
