EPSON EPL-6200/EPL-6200L Revision A
Product Description Controller Specification 39
1.4.2 External I/F Specifications
EPL-6200/EPL-6200L is equipped with the external host interfaces as listed below:
NOTE:
Switching between host interfaces is automatic only. Each interface cannot
be switched on and off individually.
Figure 1-18. Rear View (Interface Bracket)
1.4.2.1 Parallel Interface Specifications
The initial Device ID value of this printer is described below:
 EPL-6200
MFG:EPSON;CMD:PJL,EJL,ESCPL2,ESCP9,PRPXL24-01,PCL,HPGL2-01,ESCPAGE-
04,PCLXL,POSTSCRIPT;
MDL:EPL-6200;
CLS:PRINTER;
DES:EPSON EPL-6200;
 EPL-6200L
MFG:EPSON;CMD:ESCPAGES-02;MDL:EPL-6200L;CLS:PRINTER;DES:EPSON EPL-6200L;
Table 1-38. External Host Interfaces
EPL-6200 EPL-6200L
Standard
IEEE1284 parallel interface
{{
USB interface (USB Revision 1.1)
{ {
Optional Optional Type-B I/F Card slot
{
–
USB connector
Parallel I/F connector
Parallel I/F connector
USB connector
Optional Type-B I/F Card slot
EPL-6200
EPL-6200L
Table 1-39. Parallel Interface Specifications
Item Description
Interface Type IEEE 1284 bi-directional high speed parallel interface
Operating Modes Compatibility, Nibble, ECP
Connector Model Names 57RE-40360-830B (D7A) DDK or equivalent products
Conforming Plugs AMPHENOLE or equivalents
