Epson EPL-6200L - Paper Eject Process; Paper Eject Mechanism

EPSON EPL-6200/EPL-6200L Revision A
Operating Principles Description of Mechanisms 89
2.2.8 Paper Eject Process
2.2.8.1 Paper Eject Mechanism
Transports paper from the fuser area to the Paper Eject Roller.
Figure 2-28. Paper Eject Mechanism
Output Tray
Paper Eject Roll
Paper Eject Roller
Face-down Eject
