EPSON EPL-6200/EPL-6200L Revision A
Operating Principles Description of Mechanisms 76
2.2.1.5 Cooling inside the Printer
The Cooling Fan Motor discharges the heat emitted by the Print Head Unit to the
outside of the printer, thus preventing temperature rise of the Print Head Unit.
Figure 2-11. Cooling inside the Printer
