EPSON EPL-6200/EPL-6200L Revision A
Operating Principles Operating Principles of Electric Circuitry 95
COMPARISON OF EPL-6200 WITH EPL-6100
Table 2-10. Comparison of EPL-6200 with EPL-6100
Device EPL-6100 EPL-6200
CPU TMPR4955AF-200 TMPR4955BFG-200
ASIC
DLC: E05B96BA
Memory, I/O integrated controller, USB
←
Memory
Onboard MASK ROM None ←
Standard ROM-DIMM
1 slot. +3.3V DIMM.
IPL, Code, Font, SDRAM
1 slot. +3.3V DIMM. IPL, Code, Font, PS, SDRAM
Address A23 expanded
Standard ROM constitution
at initial production
Code: Flash 8/16 Mbit (x16) 2 pieces
Font: MASK 32 Mbit (x32) 1 piece
Code, Font, PS:1 6 MB
Flash 64 Mbit (x16) 2 pieces
Standard ROM constitution
by steady production
Code, Font: 8 MB
Mask 64 Mbit (x32) 1 piece
Code, Font, PS: 16 MB
Mask128 Mbit (x32) 1 piece
Font type BitStream AGFA
Option ROM-DIMM
1 slot for local language and extension ROM,
ConvROM (Board C)
+3.3V DIMM
None
Standard SDRAM
Mounted on the DIMM for code.
8 MB: 64 Mbit (x32) 1 piece
←
SDRAM-DIMM
1slot. Newly employed 90-pin. 2 / 4 pieces
16, 32, 64, 128 MB
←
EEPROM 128 Kbits, serial type, for storage of printer settings. M95128. ←
CSIC Not supported Supported (Main firmware control)
Host I/F
Parallel interface
IEEE1284 compliance, B type connector.
Separate IF board connected with FPC. Transceiver,
Protection diode: None
←
IF board connected with FPC.
(Only parallel)
USB
USB 1.1, B-type connector
Separate IF board connected with FPC.
←
Connected with harness to MAIN board.
Serial interface
None
UACLK: None
←
Onboard Network
Not mounted. Mounted at soft development.
DL10022.
←
Control Panel Control Panel Unit
New-type controller panel.
No LCD, 3 switches, 6 LEDs
LED driver: 74LCX07. FPC connection.
←
Harness connection.
Video I/F MLT NC-L601H ←
Mechanical Controller Integrated. (No Video I/F connector) ←
