Epson FX-890II User Manual

1. Remove any paper loaded on the pull tractor as described in “Removing paper from the pull
tractor” on page 38.
2. Make sure the printer is turned off. Then open the paper guide cover by pulling its back edge
toward you.
3. Lift the printer cover and pull it straight up and off the printer.
4. Press the tractor’s lock tabs, tilt the tractor toward you, and lift it off the printer.
5. Store the tractor in a safe place, or install it in the front or rear push position as described in “Using
the tractor in the front push position” on page 26 or “Using the tractor in the rear push position” on
page 21.
6. Reinstall the paper tension unit by lower it onto the printer’s mounting pegs. Then press down on
both ends of the unit until it clicks into place.
7. Replace the printer cover.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Paper Handling 39

Epson FX-890II Specifications

General

Color	No
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Character pitch	10 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	80
Product color	Black
Page description languages	ESC P, PPDS
Sound pressure level (printing)	55 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Mean time between failures (MTBF)	20000 h
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Cut sheet thickness range	0.12 - 0.46 mm
Continuous paper thickness range	0.46 - 0.46 mm
Standard interfaces	Parallel, USB 2.0

Weight and Dimensions

Depth	376 mm
Width	437 mm
Height	177 mm
