Epson FX-890II User Manual

Note:
For your safety, Epson recommends operating the printer with the printer cover closed. The printer
will function with the printer cover opened or removed, but maximum safety and print speed are
achieved when the cover is closed.
15. The printer starts printing from the top-of-form position. After you finish printing, open the
paper guide cover.
Removing paper from the pull tractor
Follow these steps to remove continuous paper from the pull tractor:
1. After you finish printing, tear off the paper supply at the perforation nearest the paper entry slot.
2. To feed paper forward and eject it, hold down the LF/FF button.
!
Caution:
Never press the Load/Eject or Tear Off/Bin button when you are using the pull tractor; the
paper could come off the pull tractor and jam the printer.
Removing the tractor from the pull position
Follow these steps to remove the tractor from the pull position:
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Paper Handling 38

Epson FX-890II Specifications

General

Color	No
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Character pitch	10 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	80
Product color	Black
Page description languages	ESC P, PPDS
Sound pressure level (printing)	55 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Mean time between failures (MTBF)	20000 h
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Cut sheet thickness range	0.12 - 0.46 mm
Continuous paper thickness range	0.46 - 0.46 mm
Standard interfaces	Parallel, USB 2.0

Weight and Dimensions

Depth	376 mm
Width	437 mm
Height	177 mm
