Epson L3260 Series User Manual

There is dust or dirt on the originals or the scanner glass.
Solutions
Remove any dust or dirt that adheres to the originals, and clean the scanner glass.
& “Cleaning the Scanner Glass” on page 124
There is dust or dirt on the ADF or originals.
Solutions
Clean the ADF, and remove any dust or dirt that adheres to the originals.
& “Cleaning the ADF” on page 125
The original was pressed with too much force.
Solutions
If you press with too much force, blurring, smudges, and spots may occur.
Do not press with too much force on the original or the document cover.
& “Placing Originals on the Scanner Glass” on page 36
The copy density setting is too high.
Solutions
Lower the copy density setting.
& “Menu Options for Copying” on page 76
Moiré (Cross-Hatch) Patterns Appear in the Copied Image
If the original is a printed document such as a magazine or a catalog, a dotted moiré pattern
appears.
Solutions
Change the reduce and enlarge setting. If a moiré pattern still appears, place the original at a slightly
dierent angle.
& “Menu Options for Copying” on page 76
Solving Problems > Printing, Copying, Scanning, and Faxing Quality is Poor > Copy Quality is Poor
214

Epson L3260 Series Specifications

General

Print Resolution	5760 x 1440 dpi
Scanner Resolution	1200 x 2400 dpi
Connectivity	USB, Wi-Fi, Wi-Fi Direct
Functions	Print, Scan, Copy
Paper Handling Input	100 sheets
Dimensions (W x D x H)	375 x 347 x 179 mm
Weight	3.9 kg
Print Technology	On-demand inkjet (piezoelectric)
Scanner Type	Flatbed colour image scanner
Print Speed (Black)	10 ipm
Print Speed (Color)	5 ppm
Copy Speed (Black)	7.7 cpm
Copy Speed (Color)	3.8 ipm (ISO/IEC 29183)
Paper Sizes Supported	A4, A5, A6, B5, Letter, Legal
Mobile Printing	Epson iPrint
Ink Colors	Black, Cyan, Magenta, Yellow
Display	1.44" Color LCD
