Specifications
General
Electrical
CPU: TMS320DM270
LCD: 3.8 inches, Epson VGA TFT LCD;
640
× 480 pixels; 262,144 colors; 212 ppi
Memory: 64MB SDRAM; 4MB flash ROM
HDD: 2.5 inch HDD, 40GB, FAT 32
Dimensions
(without
projections)
and weight:
Height 3.3 inches (84 mm)
Width 5.8 inches (147 mm)
Depth 1.2 inches (31.4 mm)
Weight Approx. 0.9 lb (415 g),
including battery
Temperature: Operating (or charging): 41 to 95 °F
(5 to 35 °C)
Non-operating: –4 to 140 °F
(–20 to 60 °C)
Humidity:
(without
condensation)
Operating: 30 to 80%
Non-operating: 10 to 80%
Memory card: 3.3V CompactFlash memory card
(Type I/ Type II, including Microdrive);
SD memory card, MultiMedia Card,
Note:
A commercially available CF adapter is
needed to use other memory cards.
Power sources: Lithium-ion battery (Model EU-97)
AC adapter (Model A351H)
Input voltage DC 5.0 V
Rated current Maximum 2.3 A
Power
consumption
4 W (with the battery)
9 W (when using the AC adapter)
