Epson PowerLite 1880 User Manual

Connecting to a Projector on a Different Subnet
20
C Edit the contents registered in the profile.
D Click OK.
Saves your edits and closes the Edit profile screen.
A
: Indicates a profile.
B
: Indicates a folder.
Profile
Item Function
Profile
You can display the registered profile. You can
manage it by creating a folder.
Copy
You can copy the profile. The copied profile is
saved in the same folder as the original with the
same name.
Delete
You can delete the profile and the folder.
Rename
You can display the Rename dialog box to
rename the folder or the profile. You can enter
up to 32 characters in the Rename dialog box.
Create folder
You can create a new folder.
Export
You can export the profile. Exported profiles can
be used as backup files. You can import them
with another computer.
Import
You can load an exported profile.
Information on selected profile
Item Function
Projector
name
The projector information registered in the
profile is displayed.
IP Address
Delete
You can delete the information for the selected
projector. When all projector information is
deleted, the profile is also deleted.

Epson PowerLite 1880 Specifications

Projection System

projection system	Epson 3LCD, 3-chip technology
native resolution	1024 x 768 (XGA)
color light output	4000 lumens

Power

power supply voltage	100 – 240 V ± 10%, 50/60 Hz AC
power consumption (normal mode)	381 W
power consumption (eco mode)	309 W

Lamp

lamp type	275 W UHE E-TORL
lamp life (normal mode)	3000 hours
lamp life (eco mode)	4000 hours

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	39 dB
fan noise (eco mode)	35 dB

Projection Lens

f-number	1.51 – 1.99
focal length	18.2mm – 29.2mm
zoom ratio	optical zoom 1.0 – 1.6

Weight and Dimensions

dimensions including feet	13.5" x 10.3" x 4.2"
dimensions excluding feet	13.5" x 10.3" x 3.6"
weight	7.4 lb
