Epson PX-603F Programming Guide

2011/03/02
Revision: 1 Page: 33
5.1.8 Set absolute horizontal print position ESC ( $ nL nH m1 m2 m3 m4
ESC ( $ nL nH m1 m2 m3 m4 Ver 1.00
[Name] Set absolute horizontal print position [Operation]
[Format] 1BH, 28H, 24H, nL, nH, m1, m2, m3, m4
[Range of Definition] nL = 04H, nH = 00H (number of bytes to follow)
0 <= m <= 47616
[Function] 1) The printing position in the positive X direction is set to:
The maximum Absolute Horizontal Position (AHP) is 209.973mm or (29760/3600 =) 8.267
inches.
Position Count (c) is given by:
c = m4*256*256*256 + m3*256*256 + m2*256 + m1
From the [ESC (U] and the [ESC (U] Extended Command
AHP AHP AHP Abs Horizontal
units Value Resolution Print Position Value
__* 0.002mm( 1/5760 inch) 5760* 0 <= n <= 47616
__* 0.004mm( 1/2880 inch) 2880* 0 <= n <= 23808
__* 0.008mm( 1/1440 inch) 1440* 0 <= n <= 11904
5 0.035mm( 5/3600 inch) 720* 0 <= n <= 5952
10 0.071mm(10/3600 inch) 360* 0 <= n <= 2976
20 0.141mm(20/3600 inch) 180* 0 <= n <= 1488
30 0.211mm(30/3600 inch) 120* 0 <= n <= 992
40 0.282mm(40/3600 inch) 90* 0 <= n <= 744
50 0.353mm(50/3600 inch) 72 0 <= n <= 595
60 0.423mm(60/3600 inch) 60 0 <= n <= 496
*See [ESC (U] Extended command for APH Units for these resolution
in general when using [ESC (U]
(256 x nH + nL) x 3600
0 <= -------------------------------- <= (29760/3600)inch
AHP_units
in general when using [ESC (U] Extended
(256 x nH + nL) x Base_Unit(m)
0 <= ----------------------------------------- <= (29760/3600)inch
AHP_units
from the origin (the left margin position) on the X axis of the position management coordinate
system.
2) If the Absolute Horizontal Position specified is passed the right margin position, then this
command is ignored.
[Initial State] -
[Related Commands]
[Setting] Commands whose settings are affected by this command.
None
[Setting] Commands that change the effects of this command.
None
[Operation] Commands whose functionality is affected by this command.
None
[Operation] Commands that change the effects of this command.
[ESC (U] sets the Absolute Horizontal Position units/value.
[ESC (G] initialize the Absolute Horizontal Position units/value.
[ESC @] initialize units for page and position values.
