2011/03/02
Revision: 1 Page: 47
5.1.22 Set relative vertical print position ESC (v nL nH mL mH
ESC (v nL nH mL mH Ver 1.00
[Name] Set relative vertical print position [Setting]
[Format] 1BH, 28H, 76H, nL, nH, mL, mH
[Range of Definition] nL=02H, nH=00H
(Relative vertical set position) = (mL + mH x 256) x (set units)
[Function] 1) The printing position in the Y direction is set to positive:
(256 x mH + mL) x (relative vertical position setting value) x 25.4mm
from the present Y printing position.
2) If the position set by this command is higher than the top margin position on the current
page, this command is ignored.
3) If the Y direction printing position set by this command extends to a non-printable area,
then the position management coordinate system is set to the next page; and the printing
position in the Y direction is reset to the origin on the Y axis of the new position
management coordinate system.
[Initial State] -
[Related Commands]
[Setting] Commands whose settings are affected by this command.
None
[Setting] Commands that change the effects of this command.
None
[Operation] Commands whose functionality is affected by this command.
None
[Operation] Commands that change the effects of this command.
The relative vertical position setting value is set by the ESC (U command.
The non-printable area is set by the ESC (c command.
The relative vertical position setting value, the non-printable area, and the printing position
in the Y direction are reset to their initial states by the ESC @ and ESC (G commands.
