2011/03/02
Revision: 1 Page: 38
5.1.13 Set unit (extended) ESC (U nL nH P V H mL mH
ESC (U nL nH P V H mL mH Ver 2.00
[Name] Set unit(extended) [Setting]
[Format] 1BH, 28H, 55H, nL, nH, P, V, H, mL mH
[Range of Definition] nL=05H, nH=00H
m = (mH*256 + mL) = {90, 120, 180, 360, 720, 1440, 2880, 5760}
P = m / {90, 120, 180, 360, 720, 1440, 2880}
V = m / {90, 120, 180, 360, 720, 1440, 2880, 5760}
H = m / {90, 120, 180, 360, 720, 1440, 2880, 5760}
where P, V, H are less or equal to m
In general: Unit = m / 'unit dpi'
[Function] 1) 1) Set the number of 0.0071mm(1/3600 inch) units for each of the following values:
Horizontal Position units
Vertical Position units
Page Management units
2) If m, P, V, H are out of range, this command is ignored.
[Initial State] VALUE length of value
Based Units (m): 360
Page management: 1/m = 1/360 inch
P = V = H: 1 => 360 DPI
[Related Commands]
[Setting] Commands whose settings are affected by this command.
None
[Setting] Commands that change the effects of this command.
None
[Operation] Commands whose functionality is affected by this command.
The relative horizontal position setting value used by the ESC \ and ESC( / commands is set.
The absolute horizontal position setting value used by the ESC $ and ESC( $ commands is set.
The relative vertical position setting value used by the ESC (v command is set.
The absolute vertical position setting value used the ESC (V command is set.
The unit page length specification value used by the ESC (C command is set.
The page format specification value used by the ESC (c command is set.
The paper dimension specification value used by the ESC (S command is set.
[Operation] Commands that change the effects of this command.
The printer settings are restored to their initial state to by the ESC @ command.
