5.1.27 Set the raster image resolution ESC (D nL nH rL rH v h
ESC (D nL nH rL rH v h Ver 1.00
[Name] Set the raster image resolution
[Format] 1BH, 28H, 44H, nL,nH, rL, rH, v,h
[Range of Definition]
nL=04H, nH=00H
0 <= v <= 127
0 <= h <=127
[Function]
1) Sets the raster image resolution ( ESC i ).
Vertical resolution : ( rH*256 + rL ) / v dpi
Horizontal resolution : ( rH*256 + rL ) / h dpi
2) Available resolutions are : 120, 360, 720dpi
3) Following parameters are supported.
This printer doesn’t have printer microweave mode.
1. In case of microweave mode off
1. Case of Driver microweave mode
Mode ESC ( D ESC i ESC(e Used Nozzle number
(H x V) h / r v / r mH*256+mL
d
360x120
4/1440
12/1440
128 10h/11h/12h/13h 128Nozzles
2. Case of printer microweave mode
No support.
[Initial State] -
[Related Commands]
[Setting] Commands whose settings are affected by this command.
The Resolution set of Raster image exerts the influence on the processing by the ESC i
command .
[Setting] Commands that change the effects of this command.
The Resolution setting of Raster image is returned to the initial states by the ESC @ and
the ESC (G commands.
[Operation] Commands whose functionality is affected by this command.
None
[Operation] Commands that change the effects of this command.
None
