Q
Hold both sides of the pressure roller, and move
while pressing it down to set.
Note:
Do not touch the shaft (grayed part in the figure) at
the top of the roller. Otherwise you might get grease
on your skin.
Normal printing
❏ Use low pressure rollers.
Move the high pressure rollers to right or left until
they contact the ends.
❏ We recommend setting the low pressure rollers to
be set at the edges of the media within 5 mm of the
edges.
❏ Position the remaining low pressure rollers within
the black square labels. There may be extraneous
low pressure rollers depending on the media width.
Position the extraneous low pressure rollers away
from the black square labels.
When transparent or milky white film is loaded
or during ink layering
❏ Use high pressure rollers only.
❏ We recommend positioning the rollers within
10 mm from the left and right edges of the media.
❏ Position the low pressure rollers away from the
black square labels.
R
If the media loading lever is lowered, the pressure
rollers set at the black square labels secure the
media.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Basic Operations
42
