Supported Media
The following media can be used with the printer.
Print quality is greatly affected by the type and quality of
media used. Choose a media suited to the task at hand.
For information on use, refer to the documentation
supplied with the media or contact the manufacturer.
Before buying media in large quantities, try printing on
a smaller sample and check the results.
c
Important:
Do not use media that is wrinkled, scuffed, torn, or
dirty.
Standard roll media system
Roll core size 2 or 3 inches
Roll outer diameter Up to 250 mm
Media width
300
*
to 1,626 mm (64 inches)
Media thickness Up to 1 mm
Roll weight Up to 40 kg
* 508 mm for ink layering.
Heavy Roll Media System
Roll core size 2 or 3 inches
Roll outer diameter Up to 300 mm
Media width
300
*
to 1,626 mm (64 inches)
Media thickness Up to 1 mm
Roll weight Up to 80 kg
* 508 mm for ink layering.
Moving and Transporting
the Printer
This section describes how to move and transport the
product.
Moving the Printer
This section assumes that the product is being moved to
another location on the same floor without traversing
stairs, ramps, or lifts. See below for information on
moving the printer between floors or to another
building.
U “Transport” on page 177
!
Caution:
Do not tilt the product more than 10 degrees
forward or back while moving it. Failure to observe
this precaution could result in the printer falling
over, causing accidents.
c
Important:
Do not remove the ink cartridges. Failure to observe
this precaution could cause the print head nozzles to
dry out.
Getting Ready
A
Confirm that the printer is off.
B
Remove the waste ink bottle.
U “Replacing the Waste Ink Bottle” on
page 120
C
Disconnect the power cords and all other cables.
D
Remove media from the media feeding unit and
auto take-up reel unit.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Appendix
176
