A to D indicates the margins on all four sides. See the following for more details.
Margin
Position
Explanation Available
Setting
Range
A Bottom
*1
This can be configured in RIP. To maintain media feeding accuracy, if the settings are less
than 5 mm or more than 17 mm, the settings are switched to 5 mm and 17 mm
respectively.
5 to 17 mm
B Top
*1
This can be configured in RIP. Differs by the length the media was pulled when the media is
loaded. For continuous printing, although the margins set in RIP are added, to maintain
media feeding accuracy, if the setting is less than 5 mm the setting is switched to 5 mm.
5 mm or more
C Left
*2, *3
The value selected for Side Margin(Left) in the printer's setup menu. The default setting is
5 mm.
3 to 25 mm
D Right
*2, *3
The total of the values selected for Print Start Position and Side Margin(Right) in the
printer's setup menu. The default setting for Print Start Position is 0 mm and Side
Margin(Right) is 5 mm.
3 to 825 mm
*1 The configured margin and the actual print results may differ depending on the RIP being used. Contact the RIP
manufacturer for more information.
*2 This may be available in the RIP depending on the software RIP being used. Contact the RIP manufacturer for
more information.
*3 Note the following points when setting margins.
❏ Leave margins of 10 mm or more when using media holding plates. Narrower margins could result in printer printing over
the plates.
❏ If the total of the print data width and set left and right margins exceeds the printable area, a portion of the data will not be
printed.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Basic Operations
92
