EPSON Stylus C110/C120/D120 Revision B
ADJUSTMENT Adjustment Items and Overview 110
5.1.2 Required Adjustments
The table below lists the required adjustments depending upon the parts being repaired or replaced. Find the part(s) you removed or replaced, and check which adjustment(s) must be
carried out.
Table 5-4. Required Adjustment List
Priority
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
EEPROM data copy
Initial setting
USB ID input
Waste ink pad counter
Ink charge
Head ID input
Top margin adjustment
First dot position adjustment
Head angular adjustment
Bi-D adjustment
Initialize
PF deterioration offset/
Disenable PF
deterioration offset
CR motor heat
protection control
PF motor heat
protection control
PF adjustment
PF band adjustment
Main board unit
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Replace
(Read OK)
O --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Replace
(Read NG)
--- O O
O
Replace
the pad
--- O O O O O
O
Input max.
value (10000)
O O O O
Printhead
Remove
--- --- --- --- --- --- O O O O --- --- --- O O
Replace
--- --- --- --- O O O O O O --- --- --- O O
Power Supply unit
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Replace
--- --- --- --- --- --- --- --- --- --- --- O O --- ---
Hopper
Remove
--- --- --- --- --- --- O O --- --- --- --- --- --- ---
Replace
--- --- --- --- --- --- O O --- --- --- --- --- --- ---
CR motor
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Replace
--- --- --- --- --- --- --- --- --- --- --- O --- --- ---
EJ roller
Remove
--- --- --- --- --- --- --- --- --- O --- --- --- O O
Replace
--- --- --- --- --- --- --- --- --- O --- --- --- O O
PF motor
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Replace
--- --- --- --- --- --- --- --- --- --- --- --- O --- ---
Main frame
Remove
--- --- --- --- --- --- --- --- O O --- --- --- --- ---
Replace
--- --- --- --- --- --- --- --- O O --- O --- --- ---
Adjustment Item
Part Name

Epson Stylus D120 Specifications

General

Color	Yes
Print head nozzles	360
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	37 ppm
Print speed (color, normal quality, A4/US Letter)	20 ppm
Total output capacity	120 sheets
Envelopes sizes	C6, DL
Custom media sizes	13 x 20 cm, 102 x 181 mm
Paper tray media types	Photo paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Compatible operating systems	Windows 98SE / ME / 2000 / XP / XP-x64 / Vista Mac OS 10.2.8
Interface	USB 2.0
Power requirements	AC 220-240 V
Compatible ink types, supplies	DURABrite Ultra Ink
USB 2.0 ports quantity	1
Sound power level (printing)	39 dB
Package depth	493 mm
Package width	294 mm
Package height	233 mm
Package weight	5046 g
Bundled software	Epson Creativity Suite, Epson Easy Photo Print, Epson Web-To-Page
Quantity per pack	1 pc(s)
Sustainability certificates	ENERGY STAR
Power consumption (standby)	2 W
Power consumption (printing)	15 W
Country of origin	Indonesia
Market positioning	Home & office
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2014 mm
Quantity per pallet	48 pc(s)
Quantity per pallet (UK)	64 pc(s)
Quantity per pallet layer	6 pc(s)
Quantity per pallet layer (UK)	8 pc(s)

Weight and Dimensions

Depth	240 mm
Width	435 mm
Height	161 mm
