Epson Stylus D120 User Manual

EPSON Stylus C110/C120/D120 Revision B
6
Contents
Chapter 1 PRODUCT DESCRIPTION
1.1 Features.................................................................................................................. 9
1.2 Printing Specifications......................................................................................... 10
1.2.1 Basic Specifications.................................................................................... 10
1.2.2 Print Mode .................................................................................................. 10
1.2.3 Supported Paper.......................................................................................... 12
1.2.4 Printing Area............................................................................................... 14
1.2.5 Ink Cartridge............................................................................................... 14
1.3 Interface............................................................................................................... 15
1.4 General Specifications......................................................................................... 15
1.4.1 Electrical Specifications ............................................................................. 15
1.4.2 Environmental Conditions .......................................................................... 16
1.4.3 Durability.................................................................................................... 16
1.4.4 Acoustic Noise............................................................................................ 16
1.4.5 Safety Approvals (Safety standards/EMI) .................................................. 16
1.5 Operation Buttons & Indicators (LEDs).............................................................. 17
1.5.1 Operation Buttons....................................................................................... 17
1.5.2 Indicators (LEDs) ....................................................................................... 17
1.5.3 Operation Buttons & LEDs Functions........................................................ 17
1.5.4 Errors & Remedies ..................................................................................... 19
Chapter 2 OPERATING PRINCIPLE
2.1 Overview ............................................................................................................. 21
2.1.1 Printer Mechanism...................................................................................... 21
2.1.2 Motors & Sensors ....................................................................................... 22
2.2 Printer Mechanism Operating Principles ............................................................ 23
2.2.1 Printhead..................................................................................................... 23
2.2.2 Carriage Mechanism................................................................................... 25
2.2.3 Paper Loading/Paper Feed Mechanism ...................................................... 26
2.2.4 Ink System Mechanism .............................................................................. 31
2.2.5 Ink Sequence............................................................................................... 34
2.3 Electrical Circuit Operating Principles................................................................ 35
2.3.1 Power Supply Board................................................................................... 35
2.3.2 C687 Main Board ....................................................................................... 36
Chapter 3 TROUBLESHOOTING
3.1 Overview ............................................................................................................. 43
3.1.1 Specified Tools ........................................................................................... 43
3.1.2 Preliminary Checks..................................................................................... 43
3.2 Troubleshooting................................................................................................... 44
3.2.1 Motor and Sensor Troubleshooting ............................................................ 44
3.2.2 Error Indications and Fault Occurrence Causes ......................................... 45
3.2.3 Superficial Phenomenon-Based Troubleshooting ...................................... 63

Epson Stylus D120 Specifications

General

Color	Yes
Print head nozzles	360
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	37 ppm
Print speed (color, normal quality, A4/US Letter)	20 ppm
Total output capacity	120 sheets
Envelopes sizes	C6, DL
Custom media sizes	13 x 20 cm, 102 x 181 mm
Paper tray media types	Photo paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Compatible operating systems	Windows 98SE / ME / 2000 / XP / XP-x64 / Vista Mac OS 10.2.8
Interface	USB 2.0
Power requirements	AC 220-240 V
Compatible ink types, supplies	DURABrite Ultra Ink
USB 2.0 ports quantity	1
Sound power level (printing)	39 dB
Package depth	493 mm
Package width	294 mm
Package height	233 mm
Package weight	5046 g
Bundled software	Epson Creativity Suite, Epson Easy Photo Print, Epson Web-To-Page
Quantity per pack	1 pc(s)
Sustainability certificates	ENERGY STAR
Power consumption (standby)	2 W
Power consumption (printing)	15 W
Country of origin	Indonesia
Market positioning	Home & office
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2014 mm
Quantity per pallet	48 pc(s)
Quantity per pallet (UK)	64 pc(s)
Quantity per pallet layer	6 pc(s)
Quantity per pallet layer (UK)	8 pc(s)

Weight and Dimensions

Depth	240 mm
Width	435 mm
Height	161 mm
