EPSON Stylus C110/C120/D120 Revision B
DISASSEMBLY/ASSEMBLY Overview 71
4.1.3 Work Completion Check
If any service is made to the printer, use the checklist shown below to confirm all
works are completed properly and the printer is ready to be returned to the user.
Classification Item
Check Point
Status
Printer Unit
Self-test Is the operation normal? OK / NG
ON-line Test
Is the printing successful? OK / NG
Printhead (Nozzle
check pattern print)
Is ink discharged normally from all
the nozzles?
OK / NG
Carriage Mechanism
Does it move smoothly? OK / NG
Is there any abnormal noise during its
operation?
OK / NG
Is the CR Motor at the correct
temperature? (Not too hot to touch?)
OK / NG
Printer Unit
Paper Feeding
Mechanism
Is paper advanced smoothly? OK / NG
No paper jamming? OK / NG
No paper skew? OK / NG
No multiple feeding? OK / NG
No abnormal noise? OK / NG
Is the paper path free of any
obstructions?
OK / NG
Is the PF Motor at correct
temperature?
OK / NG
ON-line Test ON-line Test Is the operation normal? OK / NG
Adjustment
Specified
Adjustment
Are all the adjustments done
correctly?
OK / NG
Lubrication
Specified
Lubrication
Are all the lubrication made at the
specified points?
OK / NG
Is the amount of lubrication correct? OK / NG
Function ROM Version Version: OK / NG
Packing
Ink Cartridge
Are the ink cartridges installed
correctly?
OK / NG
Waste Ink pad
Are the waste ink pads adequate to
absorb?
OK / NG
Protective materials
Is the printer carriage placed at the
capping position?
OK / NG
Others
Attachments,
Accessories
Have all the relevant items been
included in the package?
OK / NG
Classification Item
Check Point
Status

Epson Stylus D120 Specifications

General

Color	Yes
Print head nozzles	360
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	37 ppm
Print speed (color, normal quality, A4/US Letter)	20 ppm
Total output capacity	120 sheets
Envelopes sizes	C6, DL
Custom media sizes	13 x 20 cm, 102 x 181 mm
Paper tray media types	Photo paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Compatible operating systems	Windows 98SE / ME / 2000 / XP / XP-x64 / Vista Mac OS 10.2.8
Interface	USB 2.0
Power requirements	AC 220-240 V
Compatible ink types, supplies	DURABrite Ultra Ink
USB 2.0 ports quantity	1
Sound power level (printing)	39 dB
Package depth	493 mm
Package width	294 mm
Package height	233 mm
Package weight	5046 g
Bundled software	Epson Creativity Suite, Epson Easy Photo Print, Epson Web-To-Page
Quantity per pack	1 pc(s)
Sustainability certificates	ENERGY STAR
Power consumption (standby)	2 W
Power consumption (printing)	15 W
Country of origin	Indonesia
Market positioning	Home & office
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2014 mm
Quantity per pallet	48 pc(s)
Quantity per pallet (UK)	64 pc(s)
Quantity per pallet layer	6 pc(s)
Quantity per pallet layer (UK)	8 pc(s)

Weight and Dimensions

Depth	240 mm
Width	435 mm
Height	161 mm
