EPSON Stylus C110/C120/D120 Revision B
PRODUCT DESCRIPTION Operation Buttons & Indicators (LEDs) 17
1.5 Operation Buttons & Indicators (LEDs)
1.5.1 Operation Buttons
The printer has the following three operation buttons.
1.5.2 Indicators (LEDs)
Three indicators (LEDs) are provided to indicate settings or printer status.
Note *1 : The Ink LED and Paper LED stay OFF when printing from PC.
*2 : See Table 1-14 “Indicators (LEDs) Function” for the LED status at error occurrence.
Figure 1-4. Buttons & LEDs
1.5.3 Operation Buttons & LEDs Functions
Detailed information on the buttons and LEDs functions are listed below.
Note 1: First press the Paper button and then Power button. The printer will turn On and print
the nozzle check pattern.
2: First press the Power button and then Ink button. Hold them for seven seconds.
3: The nozzle check pattern printed by the printer is shown in Figure 1-5.
Table 1-11. Operation Buttons
Button Function
Power Turns the power ON/OFF.
Ink Runs a sequence of ink cartridge replacement or cleaning.
Paper Feeds or ejects paper.
Table 1-12. Indicators (LEDs)
LED Function
Power LED (green)
Lights at power-on.
Flashes during some sequence is in progress.
Flashes at high speed during power-OFF sequence.
Ink LED (orange)*
1
Lights or flashes when an ink-related error occurs.*
2
Paper LED (orange)*
1
Lights or flashes when an paper-related error occurs.*
2
Power Button Paper ButtonInk Button
Power LED Paper LEDInk LED
Table 1-13. Operation Button Functions
Button Function
Power Turns the power ON/OFF
Ink
Runs a sequence of ink cartridge replacement. The carriage
moves to set the ink cartridge to the position for
replacement.
Moves the carriage to the ink check position when ink level
low, ink out, or no ink cartridge error has occurred.
When an ink cartridge is at the ink check position, moves
the carriage to set the cartridge to the position for
replacement, or to the ink check position.
When an ink cartridge is at the ink replacement position,
moves the carriage to the home position.
Paper
Feeds or ejects paper.
Recovers from a multi-feed error and resumes the print job.
Feeds paper that is loaded on the tray when a no-paper error
has occurred.
Ejects a jammed paper when a paper jam error has
occurred.
Cancels the print job during printing.
Ink
(when held for three seconds
or longer)
Runs a head cleaning.
Runs a sequence of ink cartridge replacement when ink
level low, ink out, or no ink cartridge error has occurred.
Power + Paper *
1
(combination)
•Prints a nozzle check pattern.*
3
Power + Ink *
2
(combination)
Forcefully turns the power OFF.
