EPSON Stylus C110/C120/D120 Revision B
PRODUCT DESCRIPTION Printing Specifications 14
1.2.4 Printing Area
The printing area for this printer is shown below.
Note * : The margins for Borderless print are margins that bleed off the edges of paper.
Figure 1-2. Printing Area
1.2.5 Ink Cartridge
The product numbers of the EPSON ink cartridges for this printer are shown below.
Note * : Not supported for EHK.
Shelf life
Two years from production date (if unopened), six months after opening package.
Storage Temperature
Dimension
12.7 mm (W) x 68 mm (D) x 47 mm (H)
Table 1-5. Printing Area (Margins)
Print Mode Paper Size
Margin
Left Right Top Bottom
Standard print
Any size 3 mm 3 mm 3 mm 3 mm
Envelope 5 mm 5 mm 3 mm 20 mm
Borderless
print
A4/Letter to
5” x 7”
2.54 mm* 2.54 mm*
2.3 mm* 3.67 mm*
4” x 6” 2.3 mm* 3.39 mm*
Print Area
LM RM
TM
BM
BM
Cut Sheet (Standard)
Cut Sheet (Borderless)
Paper SIze
LM
RM
TM
BM
Print Area
LM
RM
Print Area
Envelope
Paper Size
TM
Paper Feed Direction
Table 1-6. Product No. of Ink Cartridges
Color EAI Latin Euro CISMEA Asia
Black T0681 (S) T0731H (S)
T0711H (S)
T0711 (2S)
T0731H (S)
T0731 (2S)
T0731H (S)*
T0731 (2S)
Cyan T0692 (3S) T0732 (3S) T0712 (3S) T0732 (3S) T0732 (3S)
Magenta T0693 (3S) T0733 (3S) T0713 (3S) T0733 (3S) T0733 (3S)
Yellow T0694 (3S) T0734 (3S) T0714 (3S) T0734 (3S) T0734 (3S)
Table 1-7. Storage Temperature
Situation Storage Temperature Limit
When stored in individual boxes
-20
o
C to 40
o
C
(-4
o
F to 104
o
F)
1 month max. at 40
o
C (104
o
F)
When installed in main unit
-20
o
C to 40
o
C
(-4
o
F to 104
o
F)
The ink cartridge cannot be refilled.
Do not use expired ink cartridges.
The ink in the ink cartridge freezes at -16 °C (3.2
o
F). It takes
about three hours under 25 °C (77
o
F) until the ink thaws and
becomes usable.
