Adjustment Details of Adjustments (TBD) 43
Epson Stylus Photo R3000 Revision A
The following shows print samples when adjustment of the PF Roller Shaft Center Support Positions are inside
and outside the specified value range.
Figure 2-7. Print Sample
Unevenness
Outside the specified value range Inside the specified value range
TBD
TBD
