3-38 Disassembly and Assembly Rev.C

Confidential

8. Remove the two hinge spacers from the roll paper unit. When assembling, make sure you

insert the spacers in the direction shown below.

Install in the reverse sequence of removal.

Hinge spacer

Glossy surface

Hinge spacer
