103
Appendix
Printing and Cutting Positions
Electrical Characteristics
• The values above may vary slightly as a result of paper slack or variations in the paper. Take this
into account when setting the cutting position of the autocutter.
• When removing cut paper, the remaining roll paper is pulled at the uncut section and the pitch
of the next print may be reduced. When printing after cutting paper for prints with no pitch
reduction, feed the paper about 1 mm {16/406 inches} before printing. When the Pre-feed
before next print function is enabled, this operation is performed automatically. See"Software
S
ettings" on page 48 for more details.
Opera
ting voltage DC 24V ± 7%
Current consumption
(24V, 25°C, standard print
density)
Standby Mean: 0.1 A
Operating Mean: 1.8 A
*
*: When charging at 2.1A
Note: When print ratio is approximately 18%
• Continuous printing for 50 lines (repeating 20H-7FH)
∗ Font A, 35 columns, ASCII character
• 5 lines feeding
• Autocutting
Autocutter position
Approx. 20.0 mm {0.79"}
Approx. 9.5 mm {0.37"}
Manualcutter position
Center of the print dotline
Paper feed direction
