33
Chapter 2 Setup
Connecting the Optional Wireless LAN Unit
The optional Wireless LAN cable set (OT-WL06) enables you to use the product with a Wi-Fi connection.
For more information, refer to Technical Reference Guide of the Wireless LAN cable set.
• Be sure to turn off the printer when connecting the Wireless LAN unit.
• Depending on the installation conditions of the printer and the routing for cables connected to it,
the status of the radio waves for the Wireless LAN unit may decline. If this does happen, use an
extension cable.
• When connecting a Wireless LAN unit, use one of the connectors shown in the illustration below to
prevent the unit from contacting with the printer case. If you use a USB extension cable that came
with the Wireless LAN Unit, you can use any one of the USB connectors.
A: Printer models that are not equipped with a microSD card slot
B: Printer models that are equipped with a microSD card slot
To Next Page
