Epson TM-m30II-H User Manual

98
Appendix
Printing Specifications
dpi: dots per inch
*1: Initial setting
*2: When the printer prints with the standard print density level at 25°C {77°F} and 24V.
*3: The maximum is 100 mm/s {3.94"/s} when printing ladder barcodes, 2-dimensional symbols, or multi-tone graphics.
Paper width
58 mm
Paper width
80 mm
Printing method Thermal line printing
Dot density 203 × 203 dpi
Printing
width
48/35 characters mode 52.5 ± 0.2 mm {2.07 ±
0.01"}, 420 dots
72.0 ± 0.2 mm {2.83 ±
0.01"}, 576 dots
42/32 characters mode 52.5 ± 0.2 mm {2.07 ±
0.01"}, 420 dots
68.3 ± 0.2 mm {2.69 ±
0.01"}, 546 dots
The number
of characters
48/35 characters mode Font A (12 × 24) 35 48
*1
Font B (10 × 24) 42
*1
57
Font C (9 × 17) 46 64
Special Font A 35 48
Special Font B 46 64
Kanji Font A (24 × 24) 17
*1
24
*1
Kanji Font B (20 × 24) Japanese: 21
Korean: 26
Japanese: 28
Korean: 36
42/32 characters mode Font A (12 × 24) 32 42
Font B (10 × 24) 42 54
Font C (9 × 17) 46 60
Special Font A 35 45
Special Font B 46 60
Kanji Font A (24 × 24) 16 21
Kanji Font B (20 × 24) Japanese: 21
Korean: 26
Japanese: 27
Korean: 34
Line spacing 3.75 mm {1/5"}
(initial setting, programmable by command)
Maximum print speed
*2
250 mm/s {9.84"/s}
*3
Multi-tone graphics printing Up to 16 color tones
• The print speed changes automatically depending on the applied voltage and head
temperature.
• If the data transmission speed is slower than the maximum print speed, the print speed may
fluctuate and the print result may become shaded and/or dot displacement in paper feeding
may occur. Furthermore, if the data transmission speed is much slower than the maximum print
speed, intermittent printing will occur.
