109
Appendix
Socket communication
For Ethernet interface
Communication specifications
10BASE-T/100BASE-TX
For Wi-Fi Interface
Specification
• IEEE802.11b/g/n (2.4 GHz band) or IEEE802.11a/b/g/n/ac (2.4 GHz or 5 GHz band) compliant Wi-Fi
communication compatible.
• Infrastructure mode is supported.
• Support the IP address automatic acquisition function (DHCP, APIPA).
Communication Standard
• IEEE802.11b (2.4 GHz)
• IEEE802.11g (2.4 GHz)
• IEEE802.11n (2.4 GHz)
• IEEE802.11a (5 GHz)
• IEEE802.11n (5 GHz)
• IEEE802.11ac (5 GHz)
Security
Security can be selected from among the following:
• WPA-PSK(AES)
• WPA2-Personal
• WPA2-Enterprise
Initial settings
These settings apply when the printer is initialized in the Interface Setup mode.
• Port type TCP communication port for direct
printing
• Port number 9100
• Port communication direction bidirectional
• Max. simultaneous connections 6
• Number of connections for which printing is available 1 (occupied until the connection is
released.)
• Time out: 90 seconds (changeable)
• Countries where Wi-Fi can be used are limited. Since notes are provided for each country, check the
sheet supplied with the product.
• When using wireless LAN, make sure you disconnect the LAN cable. If a LAN cable is connected,
wireless LAN is disabled.
