Erbe APC 3 Service Manual

55 / 70
7 • Maintenance and servicing
80116-941_V24392  2023-03
Plugging detection Testing and measuring equipment
Test setup
• The test specimen is connected via the VIO 3 electrosurgical unit to the
power supply.
Test procedure
1. Call up <Test Program Plugging recognition>.
2. Plug a 20192-127 patient cable into the monopolar socket. The test
program must perform the following actions on APC 3, slot 1:
– Connector type is detected: Display "not plugged" -> monopolar
display.
– Plugging counter is increased by one: XM (=monopolar connector),
XB (=bipolar connector). The plugging counter can be reset using
"Reset"
3. Unplug cable.
4. Repeat the test with patient cable 20192-110.
5. Terminate the test program with <Close>.
6. Exit the Service settings.
HF output power,
CUT, monopolar
Testing and measuring equipment
Erbe Art. No. Description
20192-127 Patient cable AE
20192-110 Patient cable AE, international
IMPORTANT! The socket is tested with two different cables. This ensures that all rel-
evant plugging contacts are detected.
Erbe Art. No. Description
20192-127 Patient cable AE
or
20192-110 Patient cable AE, international
20190-045 Electrode handle ICC/ACC
– Laboratory measuring cable
20194-070 Patient cable NE
or
20194-075 Patient cable NE, international
20100-033 Adapter cable NE
– HF power meter
