ergoline AFFINITY 700 - Cleaning or Replacing the Lamps in the Side Section; Cleaning or Replacing Lamps and Filter Panels in the Canopy

How to use this device
10/2020 1020217-00A Operating instructions – 71/96
– Remove the lamp covers at the head and foot ends.
Replacing lamps: see page 67.
Replacing starters: see page 68.
The assembly is the same process in reverse order.
12.16.7 Cleaning or replacing the lamps in the side
section
– Removing the side section panel: see page 64.
Replacing lamps:
Low pressure lamps: see page 67.
High pressure lamps and filter panels: see page 69.
Replacing starters: see page 68.
When assembling the device please note:
– Re-lock the locks 90°.
12.16.8 Cleaning or replacing lamps and filter
panels in the canopy
– Removing the canopy panel: see page 64.
