3 INSTALLATION
0449 165 160
- 13 -
© ESAB AB 2020
Adjusting the braking torque:
1. Turn the red handle to the locked
position.
2. Insert a screwdriver into the springs
in the hub.
○ Turn the springs clockwise to
reduce the braking torque.
○ Turn the springs
counter-clockwise to increase
the braking torque.
NOTE!
Turn both springs the same amount.
3.7 Connections
3.7.1 General
• The PEK must be connected by a qualified person. See separate instruction manual.
• For connection of welding power source, see separate instruction manual.
