4 OPERATION
0449 165 160
- 23 -
© ESAB AB 2020
4.8 Refilling with flux powder
1. Close the flux valve (1) on the flux hopper.
2. Remove the optional cyclone on the flux recovery
unit, if fitted.
3. Fill with flux powder.
NOTE!
The flux powder must be dry. Use
preheated flux powder only when the
flux hopper is designed for that.
4. Position the flux tube without twisting it.
5. Adjust the height of the flux nozzle above the weld
so that the correct amount of flux is delivered.
Flux coverage should be sufficient so that
penetration of the arc does not occur.
4.9 Transportation
• Disengage the wheels by turning the locking lever (1).
• Make sure the safety chain (2) is properly fastened. This prevents accidents, for
example if the carrier is not adequately locked to the foot clamp of the carriage.
NOTE!
Use the lifting eye bolt (3) when lifting the equipment.
