5 OPERATION
0463 605 001
- 22 -
© ESAB AB 2018
Figure 3. View of wire-bobbin side
1. Wire-bobbin 3. Wire-feed assembly
2. Gas valves
WARNING!
Do not place or point the torch near the face, hand or body as this may result in injury.
NOTE!
Make sure the correct wire-feed rollers are selected.
NOTE!
Remember to use the correct contact tip in the welding torch for the wire diameter
used.
